New gen controllers
and so much more are finally here, after listening and considering your comments and suggestions.
Upgraded from previous X21 Control Systems, these new controllers are trully yours! We’re just the manufacturer that make them a reality for you.
X3 Systems
Electricals should be the second last step in completing your bike build – after all mechanicals are sorted and just before final tuning.
Three complete and full-featured Control Hubs with wiring harness designed for ground up wiring job. The only main difference is your choice of handlebar switch set option:
X3.M – Multiplex Switch Set (DIY, self-supplied)
X3.P – Push-button Plug&Go Switch Set (self-return/momentary)
X3.S – Standard Plug&Go Switch Set (factory style)
Go to the Downloads section for PDF Install Worksheets.
TC3 Systems
Only has the necessary features from the X3 Control Hubs but still have everything you need for a fully functional and efficient electrical wiring. Same difference like the X3, is your choice of handlebar switch set option:
TC3.M – Multiplex Switch Set (DIY, self-supplied)
TC3.P – Push-button Plug&Go Switch Set (self-return/momentary)
TC3.S – Standard Plug&Go Switch Set (factory style)
Go to the Downloads section for PDF Install Worksheets.
ST3.P Switch Translator
For those of you that already have a fully functioning motorcycle BUT only want to swap out the standard switch set to push buttons.
ST3.P – Push-button Switch Set (DIY, self-supplied)
In-house Push-button Plug&Go Switch Set for ST3.P also available.
Go to the Downloads section for PDF Install Worksheets.
Supplementary / Auxiliary Parts
Aside from our bread and butter controllers, we’ve heard your countless concerns about other bike parts availability and their ridiculous pricing!
So we started doing something about it for y’all.
We also took it a step further by providing hardware, connectors and other doodads for simple integration with our controllers and your whole build in general for a better, smarter install.
KEY SWITCHES
A simple component yet challenging to find. We now provide you a simple plugin standard type key switch or a wireless remote version.
Go to the Downloads section for PDF Install Worksheets.
KEYX.S
Standard Key Switch
- 40amp capable
- Anti hot-wiring
- 3-position (OFF, ON, PARK)
- 2 keys
- 1.5m wire harness
- Plastic contruction corrosion resistant
- Direct plugin to TC3/X3 control hubs
- 1 year replacement warranty
KEYX.R
Standard Key Switch
- 40amp capable
- Anti hot-wiring
- 3-position (OFF, ON, PARK)
- 2 remote fobs with batteries
- Direct plugin to TC3/X3 control hubs
- 1 year replacement warranty
STARTER SOLENOID
For electric start bikes, solenoids are usually the weak link. Old and tired solenoids are problematic, could be arc welded on, barely latching on, and whatever else.
Go to the Downloads section for PDF Install Worksheets.
SOLX.200
Protected Starter Solenoid
- 200amp capable
- Low current switching
- Built-in master & spare fuse
- Includes wire connectors, terminal boots, ring terminals & mounting hardware
- Low current switching coil
- Designed for TC3 & X3 control hubs
- 1 year replacement warranty
BATTERIES
Used to power your starter and storing electricity generated by your bike for other components shouldn’t be swelling, smoking and/or worse catching fire!
Small size for tight locations in your build.
Comes with storage charger, terminal boots, screws, ring terminals.
Go to the Downloads section for PDF Install Worksheets.
BATX.155
Lithium Ferro Phosphate Battery
- 155 cranking amps
- 7.5 amp hour
- 110 * 37 * 85mm (L*W*H)
- 455g (1.01lbs)
- 1 yr replacement warranty
BATX.205
Lithium Ferro Phosphate Battery
- 205 cranking amps
- 9 amp hour
- 107 * 56 * 87mm (L*W*H)
- 410g (0.9lbs)
- 1 yr replacement warranty
BATX.410
Lithium Ferro Phosphate Battery
- 410 cranking amps
- 13 amp hour
- 135 * 65 * 93mm (L*W*H)
- 670g (1.48lbs)
- 1 yr replacement warranty
RECTIFIER + REGULATORS
Converting AC to DC but with helpful built-in features you won’t find elsewhere.
NOT COMPATIBLE with:
Anti-Gravity batteries and
NOCO batteries
Go to the Downloads section for PDF Install Worksheets.
RECX.370
Digital Rectifier + Regulator
- New gen Open-Drain design
- 370w max output power
- Trench type MOSFET design
- Multi-phase stator compatible
- Ultra fast switching digital regulator
- Low heat operation
- Solid state design for water proof & shock proof operation
- Permanent magnet & field coil stator capable
- Lead acid de-sulphate feature
- Lead acid/AGM/lithium battery type compatible
- Steady output voltage 14.25v
- Include wire connectors & mounting hardware
- Any orientation installation mounting
- Designed for TC3 & X3 control hub
- 1 year replacement warranty
RECX.570
Digital Rectifier + Regulator
- New gen Open-Drain design
- 570w max output power
- Trench type MOSFET design
- Multi-phase stator compatible
- Ultra fast switching digital regulator
- Low heat operation
- Solid state design for water proof & shock proof operation
- Permanent magnet & field coil stator capable
- Lead acid de-sulphate feature
- Lead acid/AGM/lithium battery type compatible
- Steady output voltage 14.25v
- Include wire connectors & mounting hardware
- Any orientation installation mounting
- Designed for TC3 & X3 control hub
- 1 year replacement warranty
HORN
As silly as it may sound, a simple component such as a tired and used horn could have a huge current draw in your electrical system. Rebuild and reuse? Or just get a new one? What’s your time worth?
Go to the Downloads section for PDF Install Worksheets.
HRNX.105
105dB Horn
- Low power consumption
- 105 decibel
- Simple and easy to install
- Comes with terminal connector
- 1 year replacement warranty
TYPE 2 SWITCHBACK MODULES
We’ve given switchbacks our own twist specially for motorcycles. These are stand alone modules that can be used inline on fully functioning bikes or added to a build.
Go to the Downloads section for PDF Install Worksheets.
LITEX.2SC
Switchback Module
- For front single element lights
- Marker function (dim)
- Turn signal function (bright/off loop)
- 1 year replacement warranty
LITEX.3SC
Switchback Module
- For front dual element lights
- Marker function (color1 dim)
- Turn signal function (color1,2 off/ color2 bright loop)
- 1 year replacement warranty
LITEX.1SC
Switchback Module
- For rear single element lights
- Marker function (dim)
- Turn signal function (bright/off loop)
- 1 year replacement warranty
LITEX.3DC
Switchback Module
- For rear dual element lights
- Marker function (color1 dim)
- Turn signal function (color1,2 off/ color2 bright loop)
- 1 year replacement warranty
LED BULBS, SIGNAL LIGHTS etc…
Modern and efficient LEDs without costing an arm and a leg.
LEDX.H4
Headlight Bulb
- H4 fitment
- True low and high beam reflection
- Adequate heat production to keep light housing sealed and moisture out
- Fits PLX.H4CER
PLX.H4CER
H4 Socket
- H4 fitment
- Heat resistant ceramic
- Fits LEDX.H4
LEDX.S20YR
Integrated Turn/Tail/Brake
- 20cm, turn/tail/brake
- Yellow + Red
- Works with LITEX.3DC Modules
We provide simple and easy motorcycle wiring solutions at a fair price
using modern technology electronics along with comprehensive and thorough TechService from our engineers
Customers wiring their bikes for the first time and/or have never wired anything before, with our TechService insights and guidance, average out 3 nights to finishing a fully functional and efficient electrical system. No matter who you are, we’re all about your accomplishment and will be there every step of the way until completion.
No one else would. Why not take advantage?
